• Data rates
+ 802.11g: 6/9/12/18/24/36/48/54Mbps
+ 802.11b: 1/2/5.5/11Mbps
+ 802.11n: 30/60/90/120/180/240/270/300Mbps
• Standards
IEEE 802.11n (draft)
IEEE 802.11g
IEEE 802.11b
USB 2.0
• Frequency range
2412 to 2472MHz
• Antennas
Two integrated antennas
• Security
64/128-bit WEP data encryption
Wi-Fi Protected Access (WPA,WPA2)
• Emission schemes
DSSS, OFDM
• Data modulation schemes
DBPSK, DQPSK, CCK and OFDM (BPSK/QPSK/16-QAM/64-QAM)
• System requirements
Windows XP SP2 or 2000 SP4
CD-ROM drive
20MB hard disk space
Available USB port
Transmit output power (typical)
18dbm (802.11 b)
14dbm (802.11 g/n)
• Operating voltage
5VDC +/- 10%
• Power consumption
TX: 460mA
RX: 240mA
• Dimensions
87 x 28 x 12 mm
• Operating temperature
0º to 40º C
• Storage temperature
-20º to 65º C
• Operating humidity
10% to 90% non-condensing
• Storage humidity
5% to 95% non-condensing
• Certifications
FCC Class B
CE
C-Tick
IC
